The
SEB is a plated brass low flow meter suited for clean water. It is
available in 1/2” and 3/4” thread, with union type meter couplings for
easy installation and service. This meter is ideal for flow rates
between 0.2 GPM (0.76 LPM) and 18 GPM (68.14 LPM). The SEB has only one
moving part, the propeller.
A 5-30 Vdc square wave output makes the SEB ideal for many industrial control applications. This signal interfaces easily with programmable logic controllers and computer input boards. SEB meters can also be used in conjunction with the Seametrics FT420 flow computer for reading flow rate and total flow, or AO55 for 4-20 mA output. For metering pump pacing applications, a standard PD10 pulse divider is recommended.
A 5-30 Vdc square wave output makes the SEB ideal for many industrial control applications. This signal interfaces easily with programmable logic controllers and computer input boards. SEB meters can also be used in conjunction with the Seametrics FT420 flow computer for reading flow rate and total flow, or AO55 for 4-20 mA output. For metering pump pacing applications, a standard PD10 pulse divider is recommended.
Features
- Single-jet meter
- Compact brass body
- Union couplings
- Easy installation and maintenance
- Interfaces with many controls and displays
Applications
- Industrial control operation
- Low flow situations
- Clean water
Specification
|
Sensor
|
GMR 5-30 VDC Current sinking pulse
|
|
|
Fitting
|
1/2”, 3/4”—Male NPT union
couplings
|
|
|
Materials
|
Body
|
Nikel-plated brass
|
|
Rotor Chamber
|
Brass
|
|
|
Rotor
|
Thermoplastic
|
|
|
Shaft
|
Tungsten carbide
|
|
|
Bearings
|
Water-cooled thermoplastic
|
|
|
Maximum Temperature
|
185 ̊ F (85 ̊
C)
|
|
|
Maximum Pressure
|
175 psi (12 bar)
|
|
|
Cable
|
#22 AWG 3-cond, 12′ maximum run
2,000′ (610 m)
|
|
|
Flow Range
|
1/2”: 0.2 – 10 GPM (0.76 – 37.85
LPM
|
|
|
3/4”: 0.2 – 18 GPM (0.76 – 68.14
LPM)
|
||
|
Standard K-Factor
|
1/2″: 550 pulses per gallon
|
|
|
3/4″: 330 pulses per gallon
|
||
|
Accuracy
|
± -1% of a full scale
|
|
|
Regulatory
|
CE Mark
|
|
*Specifications subject to change. Please consult our website for the most current data
Installation and Maintenance
Installation. Single-jet meters like the SEB are somewhat insensitive to upstream and downstream flow conditions. For best results, however, upstream and downstream straight pipe of five pipe diameters is recommended.Maintenance. SEB’s Hall-effect sensor and cap are field-replaceable.
Dimension
|
Diameter
|
1/2
Inch
|
3/4
Inch
|
|
A
|
2.5
|
2.5
|
|
B
|
9.2
|
10.4
|
|
C
|
2.8
|
2.8
|
|
D
|
4.35
|
5.1
|
|
E
|
3/4 in. BSPP
|
1 in. BSPP
|
|
F
|
1/2 NTP
|
3/4 NTP
|
Download Datasheet: Seametrics SEB
More info and
price please contact marketing@wmablog.com
