Electric connectors mentioned in this writing are the most common electric connector used in the industry. There are two kinds of shapes, the most common being the circle-shaped (circular connector) and square-shaped (rectangular connector).

Electrical Connector Industry


In this section, we will present some connectors under the brand name "Nanaboshi" from Japan, also "Harting" connector from Germany, "TE" connector from the UK, and "Hirose" connector which also from Japan.

Circular Connector

Rectangular Connector



Nanaboshi Connector has a various model with contacts ranging from 1 pin up to 40 pins. And also various ampere capacity ranging from 3 amperes up to 500 Ampere with low voltage at 6.6 KV

Nanaboshi Connector manufactured by Nanaboshi Electric mfg co. Ltd from Japan. And for the connection system, it is directly welded instead of using a screw. The material used in this Connector production, for housing connector is made using aluminum alloy dan zinc alloy.

The whole set of Nanaboshi Connectors consists of two main parts, plug, and receptacle, with insert contact in the form of insert pin, and often referred to as male contact, and socket insert that often referred to as female contact.

Nanaboshi connector has two types, the S type and the G type which classifications determined based to shell shape, which inside is located pin insert or socket insert.

Nanaboshi has various model and series, these are Nanaboshi connector series that are commonly used in the industry :
